| Capacity | 1500 |
|---|---|
| Lift stroke, mm | 5500 |
| Height | 90 |
| Platform length | 1650 |
| Platform Width | 1200 |
| Lift time, (s) | 150 |
| Net weight, kg | 2400 |
| Motor power | 4,6 |
| Supply voltage | 400 AC 3~/N/PE |
| Frequency | 50 |
| Rated current | 9 |
| Control voltage | 24 DC |
| Power pack location | EXT |
| Protection class | IP55 |
| Hydraulic oil | ISO 32 |
| Frame length | |
| Frame width | |
| Working temp | -20 - +50 |
.
Product: General data
